Function

Description

Card Open Door

Connect wiegand reader or RS-485 reader

Card + PIN Open Door

1. Connect BS36K Chinese series keypad reader via      wiegand or RS-485
2. Connect BS361K keypad reader via RS-485
3. Choose either PIN or Card ID to open door
4. Card + PIN open door: require 4 digits PIN;
     PIN only open door: require 8 digits PIN

PIN Open Door

Card ID Open Door

Fingerprint Open Door

Connect BS fingerprint card reader via wiegand. At the same time the following mode can be implemented: Card + Fingerprint, ID + Fingerprint, Fingerprint + PIN, Card + Fingerprint + PIN, ID + Fingerprint + PIN, Card Only, Card + PIN, PIN Only , Card ID Only etc

Super User Card Open Door

In case of emergency or system failure, make use of super user card to open door. (used with universal reader)

Connect External 26/32 Wiegand Card Reader

Yes

Connect Free Wiegand Card Reader

Yes

Connect External Keypad Reader

1. Wiegand keypad reader via wiegand connector
2. BS series keypad reader (inclusive of Chinese series reader, BS36K keypad reader)
3. BSseries universal reader

Connect External BS Fingerprint Reader

Via Wiegand

Communicate with BS610-4

Via RS-485

Push Button Open Door

Yes

Door Sensor Monitoring

Yes

Tamper Alarm

Yes

Terminal Resistance

Determine via jumper setting

Device ID Setup

Via jumper setting

Power Monitoring

Main power supply failure alarm and backup battery low voltage alarm

Connect External Battery

Yes. Automatic redirect to backup battery when power failure
